Advanced MIDI Router
Connect your devices to SiparioX
and manage your setup with a touch.
Programmable
Easily programmed using the Display Touch and the Encoder.
Transportable
Small, lightweight, strong and easy to position.
Connect your devices to SiparioX
and manage your setup with a touch.
Easily programmed using the Display Touch and the Encoder.
Small, lightweight, strong and easy to position.
SiparioX is the evolution of the MIDI router Sipario, designed to be at the center of a keyboard setup in order to always have the sounds ready to use.
The musician creates his own lineup of tracks (SCENES) and within each, program the sounds that represents with text.
During the execution you can pass from a configuration (PERFORMANCE) to another by pressing on the touch display, or, in sequence by pressing the pedal connected to SiparioX or through the backlit button that is located on the front of the device. In every moment the musician decides what to play and from which keyboard, by programming splits and layers among different sources. Programming is done without the use of PC and through touch display!
up to 20 layer (MAPS) per performance with which create splits e layers.
Splits e layers
control solo parts from your digital piano using the integrated pitch wheel.
Pitch wheel
connect a MIDI controller to SiparioX and program: faders, potentiometers and pads to send control changes and MIDI sync messages.
Programming controllers
SiparioX can be the MASTER of the setup, generating MIDI clock valorized in BPM, with the possibility to starting sequences by sending start/stop/continue MIDI messages.
Devices syncronization
Up to 3 sequencer tracks of 32 steps per PERFORMANCE.
32 - STEP SEQUENCER
> Programmable MIDI merge/router.
> Up to 20 programmable zones per performance.
> Set lists organizition for easy recall the tracks.
> Sending of program change (typically used to change sounds).
> Composition and sending of system exclusive messages.
> Sending of control changes like volume, pan, chorus, ...
> Filtering-out of control change (switching off modulation, sustain, ...).
> Remapping of control changes with custom ranges.
> Management of MIDI sequences by sending start/stop/continue.
> 32 Step Sequencer: 3 tracks of step sequncer per performance.
> Dynamic layers controlled by the velocity.
> MIDI clock generation (BPM).
> Merging and routing of an external MIDI clock.
> Customization of dynamic curve.
> Sounds transpose.
> Sending click function (typically to the drummer).
> Programmable input pedal.
> Programmable backlit button.
> Pitch generation (through on board wheel).
> Compatibility with MPE controllers.
> Backup/Recall of scenes on USB memory stick.
5 x MIDI input
5 x MIDI output
1 x USB-B power supply 5V
1 x USB-A Host MIDI Class Compliant
(HUB up to 4 ports)
1 x input PEDAL (on/off type)
700 gr
210 x 120 x 45 (mm)
metal chassis
TFT touch screen display.
Multifunction backlight button for quick access live.
Quick and easy programming thanks to the rotary encoder with push-on switch.
Pitch wheel on board.
up to 150 storable scenes
NAMM 2020
NAMM 2020
SiparioX
NAMM 2020
SiparioX
SiparioX side view.
SiparioX rear panel.
SiparioX
